VEGA Serisi 450W Modüler DC-DC Konvertör

Genel Özellikler :
Industry Leading Flexibility
Up to 11 outputs
Voltages up to 62V, Current up to 114 Amps
Screw, Fast-on or IEC connection
Worldwide approvals & CB report
Medical Approval Option
3 Year Warranty



TDK-Lambda's Vega series of DC input 450W modular supplies are fully configurable and can provide between one and ten adjustable outputs. Up to 5 modules – single or dual outputs – can be fitted with output voltages from 1.8V to 62V and output currents of up to 114 amps. No minimum loads are required and inhibit, input fail, current-share and DC-good signals are available as options. The units are certified to IEC 60950-1 with variety of cooling and case style options.

Teknik Broşür, Manuel ve Dosyalar
Benzer Ürünler


Ürün Listesi
Model Adı
Çıkış Gücü
Çıkış V/A
Construction
Data Sheet
K00018
450W
24V / 6A
5V / 60A
12V / 12A
12V / 12A
Enclosed
K00022
450W
12V / 10A
12V / 6A
5V / 60A

Enclosed
K90006
450W
12V / 18A
12V / 40A
5V / 66A
Enclosed
K00020
450W
5V / 95A
Enclosed
K00021
450W
12V / 40A
Enclosed
K00019
450W
24V / 25A
Enclosed
