High Power Density 200W/400W/600W/800W in 2U: 3.5 Inch (89mm) height |
|
Universal Input Voltage 85-265Vac, continuous operation |
|
Active Power Factor Correction (0.99 typical) |
|
Output Voltage up to 650V, Current up to 72A |
|
Constant Voltage (CV)/(CC) Constant Current auto-crossover |
|
Embedded Microprocessor Controller |
|
Built-in RS-232/RS-485 Interface Standard |
|
Global Commands for Serial RS-232/RS-485 Interface |
|
Auto-Re-Start / Safe-Start: user selectable |
|
Low Ripple & Noise |
|
Front Panel Lock selectable from Front Panel or Software |
|
Reliable Encoders for Voltage and Current adjustment |
|
Voltage & Current high resolution adjustment by digital Encoders |
|
High resolution 16 bit ADCs & DACs |
|
Software Calibration (no internal trimmers / potentiometers) |
|
Last Setting Memory |
|
Independent Remote ON/OFF (Opto-Isolated) and Remote Enable/Disable |
|
Parallel Operation with Active Current Sharing, for up to six identical units |
|
Advanced Parallel Master / Slave. Total Current is programmed and measured via the Master |
|
Remote sensing to compensate for voltage drop of power leads |
|
External Analog Programming and Monitoring (0-5V or 0-10V, user selectable) |
|
Reliable Modular and SMT Design |
|
19” Rack Mount Capability for ATE and OEM applications |
|
Cooling fan speed control for low noise and extended fan life |
|
Optional Interfaces |
|
|
LAN interface (SCPI compatible) |
|
|
IEEE 488.2 SCPI (GPIB) Multi-Drop |
- |
LabView® and LabWindows® drivers |
|
- |
Isolated Analog programming/monitoring (0-5V or 0-10V, user selectable and 4-20mA) |
|
Arbitrary functions for: |
| |
Automotive or laser simulation / 4 Pre-Programmed Functions |
|
Fast Command Processing Time |
|
Output Sequencing |
|
Four-cell Memory Settings |
|
User Programmable Signal Pins |
|
Worldwide Safety Agency Approvals; CE Mark for LVD and EMC regulations |
