CM4 Serisi 600W Doğal Soğutmalı Modular AC-DC Güç Kaynağı




Wide Range Input 85-264Vac (425W), 120-264Vac 600W (750W for 5s), 47-63Hz (Contact factory for operation on 400Hz)
Power factor 0.99 typical
Compact 4 x 7 inch size
MIL-STD-461F compliant
External voltage control
Remote programming of voltage and current
Conduction cooled
Wide output adjustment
Over temperature protection All outputs are turned off. After unit cools down, recycle AC or toggle global remote on/off
Remote sense
AC_OK signal Open collector, high on fail
Global DC power good Open collector, high on fail if any module is <90% of set voltage
Global inhibit/enable Turns off or on all modules and the converter
Internal temperature sensor 0 to ~3V signal proportionate to converter transformer temperature
Uygulama Alanları


Açıklama
The CM4 range is the world's first conduction cooled modular power supply with a conduction cooled rating of 600W and up to 750W peak power for 5 seconds with up to 4 programmable outputs. CM4 may also be configured as convection or forced air cooled. Combining a 4kVac (2 x MOPP) input-to-output isolation and an 1 x MOPP input-to-ground isolation, the CM4 is certified for for medical and industrial equipment. 5V / 1A standby output is standard on all models and all output modules are supplied with remote sense and remote on/off.

Teknik Broşür, Manuel ve Dosyalar
Benzer Ürünler


Ürün Listesi
Model Adı
Çıkış Gücü
Çıkış Gerilimi
Gerilim Ayar Aralığı
Çıkış Akımı
Construction
Datasheet
