VEGA-LITE Serisi 500, 700&900W Modüler AC-DC Güç Kaynağı

Genel Özellikler :
1 - 11 çıkışlı (inc. standby voltage)
480W to 900W
Voltages from 1.8 to 56V
Current up to 60 Amps
Worldwide approvals & CB report
Screw Connection
Medical Approval with Low Leakage Current



The Vega-Lite modular power supply series utilises a sub-set of Vega modules, enabling the output power to be increased to 550W and 750/900W. Like the Vega series, there is no minimum loading and up to five modules can be selected to provide one to ten outputs. Both IEC 60950-1 and medical 60601-1 certifications are available with a variety of signalling and two earth leakage current options.

Teknik Broşür, Manuel ve Dosyalar
Benzer Ürünler


Ürün Listesi
Model Adı
Part No
Çıkış Gücü
Çıkış V/A
Construction
Data Sheet
V50009W
480W
12V / 40A
Enclosed
V50008K
600W
24V / 25A
Enclosed
V7000CP
600W
24V / 25A
Enclosed
V7000GJ
700W
12V / 10A
12V / 6A
5V / 60A
3.3V / 35A
Enclosed
V7000FQ
700W
24V / 10A
5V / 60A
12V / 10A
12V / 6A
Enclosed
V7000HF
700W
12V / 18A
5V / 60A
12V / 18A
Enclosed
V5FSS 15/12H3/3S 5/15H1H/3S
V506CCB
500W
Enclosed
V5FSSF 15/12H3/3S 5/15H1H/3SR
V506P9V
500W
Enclosed
V7FSS 5L1S 12C3S 24D5S
V70331R
700W
Enclosed
V6FSF 24C5 3.3C1 5D1H 15/15H3/3
V500K6R
500W
Enclosed
