QM Serisi 550-2000W Modular AC-DC Güç Kaynağı


	Giriş çalışma gerilimi
	QM4: 90-264Vac (550W), 180-264Vac (650W);
	QM5: 90-264Vac (700W), 180-264Vac (800W, 1200W);
	QM7: 90-264Vac (1200W), 150-264Vac (1500W);
	QM8: 90-264Vac (1200W), 180-264Vac (1500W, 2000W)
	BF ready full medical isolation (MOPP)
	Up to 18 outputs
	Low speed, low audible noise fan
	Industry Leading
	PMBus™ communication option
	Remote monitoring and control
	-20°C to 70°C operational, -40°C to 70°C storage (max 12 months).

Uygulama Alanları

Açıklama

The high efficiency modular QM range is available in system fan and low noise fan versions. The 5 models (QM4, QM5, QM5H, QM7 and QM8) within the range cover the range from 550W-1200W low line and 650W-2000W high line.

Combining 1 MOPP (1.5kVac) input to ground, 2 MOPP (4kVac) input to output and 1 MOPP (1.5kVac) output to ground isolation, the entire QM range is certified for both medical equipment (making it suitable for BF (body floating) type) and industrial.

High efficiency levels of up to 91% are combined with a wide selection of modules to perfectly match your requirement.

Teknik Broşür, Manuel ve Dosyalar

Benzer Ürünler

	QM4 Datasheet
	QM5 Datasheet
	QM7 Datasheet
	QM8 Datasheet
	QM4 Installation Manual
	QM5 Installation Manual
	QM7 Installation Manual
	QM8 Installation Manual
	QM Range Application Notes
	QM PMBus™ Application Notes
	3D Drawings
	Ürün resmi

	ALPHA (CA) Serisi 1000W-1500W Modular AC-DC Güç Kaynağı
	CM4 Serisi 600W Doğal Soğutmalı Modular AC-DC Güç Kaynağı
	NV-Power 50-300W Configurable AC-DC Güç Kaynağı
	NV-Power 151-1150W Moduler AC-DC Güç Kaynağı
	QM Moduler 550-2000W Moduler AC-DC Güç Kaynağı
	Vega 300-900W Moduler AC-DC Güç Kaynağı
	Vega-Lıte 480-900W Moduler AC-DC Güç Kaynağı

Ürün Listesi

Model Adı

Çıkış Gücü

Çıkış Gerilim/Akım

Construction

Datasheet

QM4 (up to 10 outputs)	650	2.8V - 105.6V / 110A	Enclosed
QM5 (up to 12 outputs)	800	2.8V - 105.6V / 110A	Enclosed
QM5H (up to 12 outputs)	1200	2.8V - 105.6V / 110A	Enclosed
QM7 (up to 16 outputs)	1500	2.8V - 105.6V / 110A	Enclosed
QM8 (up to 18 outputs)	1500	2.8V - 105.6V / 110A	Enclosed
QM8B (up to 18 outputs)	2000	2.8V - 105.6V / 110A	Enclosed
