Giriş çalışma gerilimi 85-265VAC (47-63Hz), 120-370VDC |
|
Power Factor Corrected 0.99 at 100VAC, 0.95 at 200VAC, Meets EN61000-3-2 |
|
Dual outputs |
|
200% Peak Power capability on 24V output |
|
Individual output adjustment |
|
Input Transient Protected |
|
100, 150, 225W çıkış güçlerinde |
|
Long e-cap lifetime |
|
Overcurrent Protection 5V output: >105%, 24V output: >205% |
|
Overvoltage Protection 120- 145% |
|
Remote On/Off On 24V output only, remove jumper to shutdown |
|
Operating Temperature (Open frame or L bracket) -10°C to +70°C, derate linearly to 0% load from 50°C to 70°C |
|
Operating Temperature (With /A cover option) -10°C to +60°C, derate linearly to 0% load from 40°C to 60°C |
| |
|
| |
|
